ZKTeco ProID-20WE Waterproof Reader

The ZKTeco ProID-20WE is a durable, waterproof RFID access control reader designed for secure authentication in both indoor and outdoor environments. Engineered with an IP65-rated enclosure, this compact device ensures resistance to water and dust, making it suitable for demanding weather conditions. With its fast card recognition speed, pulsing LED indicators, and support for Wiegand communication, the ProID-20WE delivers reliable performance for commercial, residential, or industrial access control applications. It integrates easily with a wide range of access control panels and systems, offering robust functionality in a sleek and modern design.

Product Features

Waterproof and Weather-Resistant Design

Built with an IP65-rated enclosure, the ProID-20WE is ideal for outdoor installation, protecting against rain, dust, and harsh environmental conditions.

Fast and Reliable RFID Reading

Supports 125kHz RFID card reading with a recognition range of up to 5 cm and a rapid reading time of 300 milliseconds for seamless user access.

Configurable Wiegand Output

Features on-site adjustable Wiegand output (26-bit or 34-bit), ensuring compatibility with various access control panels and systems.

External LED and Buzzer Control

Includes input ports for external LED and buzzer control, providing enhanced flexibility for integration with third-party security devices and visual/audio alerts.

Sleek and Compact Form Factor

A minimal black housing with pulsing white LED standby light blends well with modern architectural styles while offering professional functionality.

Product Specifications

• Brand: ZKTeco
• Model: ProID-20WE
• Product Type: RFID Reader
• Card Technology: 125kHz RFID
• Reading Range: Up to 5 cm
• Reading Time: 300 ms
• Output Format: Wiegand 26-bit or 34-bit (adjustable)
• Input Ports: External LED Control, External Buzzer Control
• Audio Feedback: Beep on read
• LED Indicator: Pulsing white (standby), active pulsing (read)
• Power Supply: 7V to 13V DC
• Current Draw: Less than 80mA
• Ingress Protection: IP65 (waterproof and dustproof)
• Operating Temperature: -10°C to +65°C
• Operating Humidity: 10% to 90% RH (non-condensing)
• Dimensions: 90 × 90 × 16 mm
• Body Color: Black
• Country of Origin: China
• Warranty: 1 Year Brand Warranty (Excludes physical or burn damage)
