RISCO ProSYS Plus 16-Zone Expander – RP512EZ16 Wired Zone Expansion Module

The RISCO ProSYS™ Plus 16-Zone Expander (RP512EZ16) is a high-performance wired input module that allows users to scale their intrusion detection systems efficiently. Designed specifically for integration with ProSYS™ Plus, this expander increases the number of physical zone inputs, enabling support for additional detectors and wired security sensors. Whether you’re upgrading a large commercial security system or expanding coverage in a complex facility, the RP512EZ16 offers flexibility, durability, and seamless system integration.

Product Features

Scalable Wired Zone Expansion

Increase your system capacity with up to 32 zone expanders, each providing 16 additional wired inputs, for a total of over 500 wired zones when fully expanded. This makes it ideal for medium to large-scale installations.

4-Wire BUS Connectivity

The RP512EZ16 connects to the ProSYS™ Plus control panel using RISCO’s 4-wire BUS, simplifying wiring and installation while maintaining robust communication and reliability.

Flexible Zone Configuration

Supports 22 programmable zone types, allowing you to define the behavior of each input zone based on your security strategy, including door contacts, motion sensors, glass break sensors, and more.

Programmable Loop Response

Customize the response time for each zone input independently, fine-tuning the performance for high-sensitivity or delayed detection zones depending on the application.

Multiple Zone Termination Options

Supports multiple zone wiring configurations:

• Normally Closed (N/C)
• Normally Open (N/O)
• End-of-Line (EOL) Resistor
• Double End-of-Line (DEOL) Resistor
  This ensures compatibility with a wide range of wired detectors and tamper monitoring requirements.

Switched Auxiliary Power Output

Equipped with a dedicated switched auxiliary power output, ideal for powering external detectors or devices directly from the expander without additional power modules.

Product Specifications

• Model: RP512EZ16
• Product Type: Wired zone expander
• Compatible System: RISCO ProSYS™ Plus
• Number of Wired Inputs: 16
• Maximum Expanders per System: 32
• Zone Types: 22 programmable zone types
• Zone Termination Options: N/C, N/O, EOL, DEOL
• Programmable Loop Response: Supported per zone
• Communication Interface: 4-wire BUS
• Auxiliary Power Output: Switched power output for external devices
• Mounting: PCB format, suitable for integration into system enclosures
• Use Case: Commercial and large-scale intrusion detection systems
