Dahua DH-HAC-HFW1200CP-A 2MP Audio Bullet Camera HD Analog with Mic

The Dahua DH-HAC-HFW1200CP-A 2MP Audio Bullet Camera is a high-performance surveillance camera that combines superior video clarity with built-in audio capabilities. Its advanced 2MP CMOS sensor delivers crisp, detailed footage, while integrated infrared (IR) illumination ensures reliable performance in low-light conditions. Designed for robust security applications, this camera supports multiple video formats, including CVI, TVI, AHD, and CVBS, for versatile integration. This camera provides reliable monitoring in diverse environments With durable IP67-rated housing and advanced imaging features such as DWDR, BLC, and 2D NR.

Product Features

High-Performance CMOS Image Sensor The camera is equipped with a 1/2.7-inch CMOS sensor, delivering a maximum resolution of 1920×1080 for crystal-clear video. Progressive scanning ensures smooth, detailed images with minimal noise. Built-in microphone for Audio Surveillance Capture both video and audio with the integrated microphone, which enhances situational awareness by recording environmental sounds for comprehensive monitoring. Flexible Lens Options Choose between two fixed-focal lens options: 2.8mm for wide-angle coverage or 3.6mm for more focused views. Both options provide excellent depth of field and sharp image quality. Robust Day/Night Functionality The automatic IR-Cut filter ensures clear video during both day and night, with an IR illumination range of up to 30 meters (98.4 feet). This makes it ideal for 24/7 surveillance. Advanced Imaging Features The camera includes key technologies like DWDR, BLC, and HLC for optimal image clarity in challenging lighting conditions. Additionally, 2D noise reduction minimizes distortion in low-light environments. Weatherproof and Durable Design With an IP67-rated enclosure, the camera is protected against dust and water, making it suitable for outdoor applications even in harsh weather. Multiple Video Format Support The camera supports CVI, TVI, AHD, and CVBS video formats, ensuring compatibility with a wide range of DVR systems. Switching between formats is easy, allowing for flexible installations. Smart IR Technology Smart IR automatically adjusts the intensity of the infrared LEDs to prevent overexposure in close-up views, maintaining image clarity even in complete darkness.

Product Specifications

Camera

• Image Sensor: 1/2.7-inch CMOS
• Max. Resolution: 1920(H) × 1080(V) (2MP)
• Scanning System: Progressive
• Electronic Shutter Speed: PAL: 1/25s–1/100000s; NTSC: 1/30s–1/100000s
• S/N Ratio: >65dB
• Min. Illumination: 0.02Lux/F1.9, 30IRE, 0Lux IR on
• Illumination Distance: 30 m (98.4 ft)
• Illuminator Control: Auto; manual
• Pan/Tilt/Rotation Range: Pan 0°–360°, Tilt 0°–90°, Rotation 0°–360°

Lens

• Lens Type: Fixed-focal, M12 mount
• Focal Length: 2.8mm or 3.6mm
• Max. Aperture: F1.9
• Field of View:
  • 2.8mm: 119° x 101° x 54° (diagonal x horizontal x vertical)
  • 3.6mm: 100° x 84° x 45°
• Close Focus Distance:
  • 2.8mm: 0.5 m (1.7 ft)
  • 3.6mm: 0.8 m (2.6 ft)

Video

• Frame Rate:
  • CVI: 1080P@25/30fps; 720P@25/30fps; 720P@50/60fps
  • AHD/TVI: 1080P@25/30fps; 720P@25/30fps
  • CVBS: 960H
• Day/Night: Auto switch by ICR
• White Balance: Auto; Manual
• BLC/WDR: BLC/HLC/DWDR
• Noise Reduction: 2D NR
• Smart IR: Yes
• Electronic Defog: Yes
• Privacy Masking: Up to 8 configurable areas

Environmental and Physical

• Weatherproof Rating: IP67
• Weight: 1 kg
• Operating Temperature: -40°C to +60°C (-40°F to +140°F)
• Power Supply: DC12V ±30%
