Honeywell ScanPal EDA60K Mobile Computer

The Honeywell ScanPal EDA60K is a rugged and versatile mobile computer built for demanding environments such as retail, warehousing, logistics, and field service. With a high-performance Qualcomm Snapdragon processor, advanced barcode scanning capabilities, and robust wireless connectivity, the EDA60K empowers workers to collect and manage data quickly and efficiently. Designed to withstand tough conditions, it offers a long-lasting battery, drop resistance, and IP64 protection, ensuring reliable performance throughout the workday.

Product Features

Powerful Performance with Snapdragon Processor

The EDA60K is powered by a Qualcomm Snapdragon 660 octa-core processor running at 2.2 GHz, delivering fast, efficient operation for enterprise applications. It is equipped with 2 GB of RAM and 16 GB of flash storage, expandable via microSD for additional capacity.

Rugged Design for Harsh Environments

Built to endure challenging conditions, the EDA60K is IP64 rated for protection against dust and water spray. It withstands drops from up to 1.5 meters and endures 1000 tumbles from 0.5 meters, making it ideal for industrial and outdoor use.

Extended Battery Life

Equipped with a 5100 mAh lithium-ion battery, the EDA60K supports up to 12 hours of continuous use on a single charge. For extended shifts, the battery is easily replaceable to maximize uptime and reduce interruptions.

Advanced Barcode Scanning

With an integrated 1D/2D barcode scanner using the N6603, SE4750SR, or SE4750DP engine options, the EDA60K delivers fast, accurate scanning for standard and high-density barcodes, improving workflow and operational speed.

High-Resolution Cameras

The 13 MP rear-facing camera with autofocus and flash allows for capturing high-quality images, useful for proof of delivery or inspection tasks. A 5 MP front-facing camera is also included for video calls or identification.

Large Touchscreen Display

The 4-inch capacitive touchscreen provides a clear, responsive interface for navigating apps, scanning items, and managing tasks, even in harsh lighting conditions.

Full Wireless Connectivity

Stay connected with 802.11 a/b/g/n/ac Wi-Fi, Bluetooth 5.0, and 4G LTE (available in select models). Integrated NFC support allows for seamless proximity communications and device pairing.

Product Specifications

• Processor: Qualcomm Snapdragon 660 octa-core, 2.2 GHz
• Operating System: Android 10 with Google Mobile Services
• Memory: 2 GB RAM, 16 GB Flash, expandable via microSD
• Battery: 5100 mAh lithium-ion, replaceable, up to 12 hours typical usage
• Display: 4-inch capacitive touchscreen
• Barcode Scanner: 1D/2D barcode imager (N6603, SE4750SR, or SE4750DP)
• Rear Camera: 13 MP with autofocus and flash
• Front Camera: 5 MP
• NFC: Integrated
• Wireless Connectivity: Wi-Fi (802.11 a/b/g/n/ac/d/h/i/k/r), Bluetooth 5.0, 4G LTE
• Drop Resistance: 1.5 meters to concrete
• Tumble Resistance: 1000 tumbles at 0.5 meters
• Ingress Protection: IP64 dust and water spray resistant
• Operating Temperature: -20°C to 50°C
• Storage Temperature: -30°C to 70°C
• Humidity: 10% to 90% (non-condensing)
