Ubiquiti UniFi Access Point UAP-AC-LITE – Dual-Band 802.11ac Wi-Fi Access Point

The Ubiquiti UniFi UAP-AC-LITE is a compact, dual-band Wi-Fi access point engineered for high-performance wireless networks. Supporting the 802.11ac standard, it offers simultaneous dual-band connectivity with speeds of up to 867 Mbps on the 5 GHz band and 300 Mbps on the 2.4 GHz band. Ideal for small to medium-sized businesses, offices, or dense residential environments, the UAP-AC-LITE combines enterprise-grade performance with an ultra-sleek form factor. With a coverage range of up to 122 meters (400 feet) and easy integration into the UniFi Network platform, it delivers seamless, scalable wireless networking.

Product Features

Simultaneous Dual-Band Wi-Fi

The UAP-AC-LITE supports both 2.4 GHz and 5 GHz bands simultaneously, enabling better performance and less interference in dense wireless environments.

• 2.4 GHz band delivers speeds up to 300 Mbps
• 5 GHz band delivers speeds up to 867 Mbps

2×2 MIMO Technology

Equipped with 2×2 MIMO antennas per band, the access point enhances throughput and reliability for multiple users, making it ideal for high-density environments such as offices, classrooms, and hospitality spaces.

Scalable UniFi Network Integration

Part of the UniFi Network ecosystem, the UAP-AC-LITE can be managed via the UniFi Controller or UniFi mobile app. Monitor network performance, manage users, create VLANs, and configure advanced features through a single centralized platform.

Flexible Mounting and Compact Design

Designed for both wall and ceiling mounting, the access point is compact and discreet. It fits seamlessly into professional and home environments without compromising aesthetics.

Enterprise Security and Guest Controls

Supports advanced wireless security protocols including WEP, WPA-PSK, and WPA-Enterprise (WPA/WPA2). The UAP-AC-LITE also enables guest traffic isolation, VLAN support, and per-user rate limiting for enhanced control.

Passive PoE Support

Powered via 24V Passive PoE, the device simplifies installation by combining power and data over a single Ethernet cable. A compatible PoE adapter is included in most packages.

Product Specifications

• Wi-Fi Standards: 802.11a/b/g/n/ac
• Wireless Speeds:
  • 2.4 GHz: Up to 300 Mbps
  • 5 GHz: Up to 867 Mbps
• MIMO Configuration: 2×2 for both 2.4 GHz and 5 GHz
• Networking Interface: 1 x 10/100/1000 Ethernet port
• Antenna Gain: 2 x Dual-band antennas, 3 dBi each
• Max Transmit Power:
  • 2.4 GHz: 20 dBm
  • 5 GHz: 20 dBm
• Power Method: Passive PoE (24V), using pairs 4, 5+ and 7, 8 return
• Power Supply: 24V, 0.5A Gigabit PoE adapter (included in many bundles)
• Max Power Consumption: 6.5W
• BSSID: Up to four per radio
• Security: WEP, WPA-PSK, WPA-Enterprise (TKIP/AES)
• QoS: Advanced per-user rate limiting
• VLAN Support: 802.1Q
• Guest Isolation: Supported
• Concurrent Clients: 200+
• Mounting Options: Wall and ceiling (mounting kits included)
• Dimensions: 160 x 160 x 31.45 mm (6.3 x 6.3 x 1.24 inches)
• Weight:
  • Device: 170 g (6.0 oz)
  • With mounting kits: 185 g (6.5 oz)
• Operating Temperature: -10°C to 70°C (14°F to 158°F)
• Operating Humidity: 5% to 95% non-condensing
• Certifications: CE, FCC, IC
• Supported Data Rates:
  • 802.11a/g: 6–54 Mbps
  • 802.11b: 1–11 Mbps
  • 802.11n: 6.5–300 Mbps (HT20/40, MCS0–MCS15)
  • 802.11ac: 6.5–867 Mbps (VHT20/40/80, MCS0–MCS9)
