Ubiquiti UniFi 24-Port PoE Switch (USW-24-POE)

The Ubiquiti UniFi USW-24-POE is a powerful and flexible managed Gigabit Ethernet switch designed for enterprise networks. It features 24 Gigabit Ethernet ports, including 16 PoE+ ports (IEEE 802.3af/at), making it ideal for powering PoE devices like UniFi Access Points and IP Cameras. The switch also provides 2 SFP ports for fiber uplinks, ensuring that it can handle high-speed connections for network expansion or integration with other enterprise infrastructure. With its fanless, silent cooling design, the USW-24-POE operates quietly, making it perfect for office or business environments where noise reduction is important.

Product Features

High Port Density with PoE+ Support

• 24 Gigabit Ethernet Ports (10/100/1000 Mbps)
• 16 Ports with PoE+ (802.3af/at) for powering devices like UniFi Access Points and IP cameras without needing separate power adapters or cables.

Fiber Uplink Ports

• 2 SFP Ports for fiber optic uplinks, supporting up to 1 Gbps speeds for long-distance connectivity to other parts of your network.

Fanless Design for Silent Operation

• The fanless design ensures silent thermal cooling, making the USW-24-POE suitable for noise-sensitive environments, including workspaces, offices, and homes.

Advanced Switching Performance

• The switch offers full Layer 2 support and the ability to process traffic on all ports simultaneously at line rate without any packet loss. This ensures high performance, even in demanding network environments.

Compact Form Factor

• The switch is designed to fit into 1U rack space, but its compact depth of only 7.9 inches allows it to be easily mounted in a rack, placed on a desktop, or installed in a SOHO (Small Office/Home Office) rack cabinet.

Comprehensive Management via UniFi Network Controller

• The USW-24-POE is fully managed through the UniFi Network Controller, offering an intuitive graphical user interface (GUI) for monitoring, configuring, and troubleshooting. It also supports UniFi mobile app for remote management from anywhere.

Product Specifications

Physical Characteristics

• Height: 1.7 inches (1U Rack-Mountable)
• Width: 17.4 inches
• Depth: 7.9 inches
• Weight: Approximately 3.6 kg (7.9 lbs)
• Form Factor: Rack-mountable and Desktop

Networking Interfaces

• Total Network Ports: 24
  • 16 PoE+ Ports: 10/100/1000 Mbps (802.3af/at PoE+)
  • 8 Non-PoE Ports: 10/100/1000 Mbps
  • 2 Uplink Ports (SFP): 1 Gbps for fiber connectivity
• Expansion Slots: 2x SFP (mini-GBIC) Slots

Media & Performance

• Media Types Supported: Optical Fiber, Twisted Pair (Ethernet)
• Ethernet Technology: Gigabit Ethernet (10/100/1000Base-T), 1000Base-X
• Network Technology: 10/100/1000Base-T (RJ45), 1000Base-X (SFP)

Management & Protocols

• Layer Supported: Layer 2 (Switching)
• Manageable: Yes (via UniFi Network Controller)

Power Description

• Power Source: External Power Supply
• Power Supply: Internal, providing the power needed for both the switch and PoE devices
• PoE Power Budget: 250W (Total PoE available to power connected devices)

Environmental Specifications

• Operating Temperature: -5°C to 40°C (23°F to 104°F)
• Operating Humidity: 10% to 90% non-condensing
• Shock and Vibration Compliance: ETSI300-019-1.4 Standard

Certifications

• Certifications: CE, FCC, IC

Other Features

• Fanless, Silent Cooling: Ensures quiet operation in noise-sensitive environments.
• 1U Rack-Mountable: Designed for easy installation in standard server racks.
