Ubiquiti UniFi 16-Port PoE Switch (USW-16-POE)

The Ubiquiti USW-Lite-16-Poe is a versatile and cost-effective 16-port switch designed to meet the needs of small to medium-sized networks. Featuring a combination of eight Gigabit Ethernet PoE+ ports and eight non-PoE ports, this switch provides flexibility for powering devices such as IP cameras, access points, and VoIP phones, while also delivering high-speed data connectivity for other network devices. The fanless design ensures quiet operation, making it ideal for noise-sensitive environments, and its durable metal and plastic casing guarantees reliable performance in various conditions. With a 45W PoE budget and advanced management capabilities through the UniFi Network Controller, the USW-Lite-16-Poe offers an all-in-one solution for modern network infrastructures.

Product Features

Power Over Ethernet (PoE+) Support

The Ubiquiti USW-Lite-16-Poe features eight PoE+ ports that support the 802.3af/at standards, providing both power and data connectivity to compatible devices. This allows for streamlined network installations without the need for separate power adapters, making it perfect for powering devices such as IP cameras, wireless access points, and VoIP phones.

Flexible Non-PoE Ports

In addition to the PoE+ ports, the switch offers eight non-PoE Gigabit Ethernet ports for devices that do not require power over Ethernet. This combination of PoE+ and non-PoE ports provides maximum versatility and ensures compatibility with a wide range of network devices.

High-Performance Switching

With a total non-blocking throughput of 16 Gbps and a switching capacity of 36 Gbps, the USW-Lite-16-Poe is designed to handle high-bandwidth applications with ease. Its forwarding rate of 26.78 million packets per second (Mpps) ensures fast and efficient data transmission, even for demanding applications.

Easy Management with UniFi Controller

Managing the USW-Lite-16-Poe is simple with the UniFi Network Controller or the UniFi Network Application. These platforms provide centralized control for configuration, monitoring, and management, allowing network administrators to easily implement VLANs, monitor traffic, and optimize network performance with an intuitive user interface.

Product Specifications

• Total Ports: 16 Gigabit Ethernet ports (8 PoE+, 8 non-PoE)
• PoE+ Budget: 45W (30W max per PoE+ port)
• PoE Standards: 802.3af/at PoE+
• Switching Capacity: 36 Gbps
• Non-Blocking Line Rate: 16 Gbps
• Forwarding Rate: 26.78 Mpps
• Management Interface: In-Band Ethernet
• Max Power Consumption: 15W (excluding PoE output)
• Power Supply: Internal 60W AC/DC power supply
• Power Method: Universal AC input (100-240V AC)
• Dimensions: 191.7 x 185 x 43.7 mm (7.55 x 7.28 x 1.72 inches)
• Weight: 1.2 kg (2.65 lb)
• Operating Temperature: -15 to 40°C (5 to 104°F)
• Operating Humidity: 10 to 90% non-condensing
• Certifications: CE, FCC, IC
• LED Indicators: Power, Ethernet, PoE
• Rack-Mountable: Yes, includes mounting accessories
