Ubiquiti Networks UniFi U7 Pro Wall Tri-Band Wi-Fi 7 Access Point

Deliver high-performance wireless coverage to your home or business with the Ubiquiti UniFi U7 Pro Wall Tri-Band Wi-Fi 7 Access Point. Designed for seamless integration, this wall-mounted access point supports the latest Wi-Fi 7 (802.11be) standard, offering ultra-fast throughput up to 10,688 Mb/s across the 2.4 GHz, 5 GHz, and 6 GHz bands. Ideal for high-density environments, it can support over 300 concurrent users while maintaining stable, low-latency connectivity for 8K streaming, real-time collaboration, and smart device usage.

With a discreet flat design and versatile mounting options, the UniFi U7 Pro Wall blends effortlessly into both modern and professional spaces. Power and data are delivered through a single 2.5 GbE PoE+ connection, simplifying installation. Network management is made easy via the UniFi Network platform, available on both web and mobile interfaces.

Product Features

Wi-Fi 7 with Tri-Band Support

Utilizes the latest Wi-Fi 7 (802.11be) standard with tri-band connectivity—2.4 GHz, 5 GHz, and 6 GHz—for maximum wireless performance and capacity.

High-Speed Performance

Achieves a total wireless throughput of up to 10,688 Mb/s:

• 6 GHz: 5700 Mb/s
• 5 GHz: 4300 Mb/s
• 2.4 GHz: 688 Mb/s

Enterprise-Class Security

Protects wireless communications with advanced security protocols including WPA, WPA2, and WPA3 (PSK and Enterprise modes).

PoE+ Power and 2.5 GbE Uplink

Includes a single 2.5 Gb/s RJ45 port that supports Power over Ethernet Plus (PoE+ 802.3at), reducing cable clutter and simplifying deployment.

Optimized for High-Density Environments

Supports over 300 simultaneously connected clients and up to 24 SSIDs, ideal for offices, hospitality, education, and commercial deployments.

Seamless Management with UniFi

Manage, configure, and monitor your network with the UniFi Network Controller via desktop or mobile (iOS & Android).

Compact and Discreet Installation

Flat wall-mounted design measures only 5.9 x 4.1 x 1.4 inches and fits seamlessly into indoor environments with ceiling mount support also available.

Product Specifications

• Wi-Fi Standard: Wi-Fi 7 (802.11be)
• Bands: Tri-Band (2.4 GHz, 5 GHz, 6 GHz)
• MU-MIMO: 2×2 per band
• Total Wireless Throughput: 10,688 Mb/s
  • 6 GHz: 5700 Mb/s
  • 5 GHz: 4300 Mb/s
  • 2.4 GHz: 688 Mb/s
• Antenna Gain: 4 to 6 dBi (internal antennas)
• Transmit Power: 22 to 26 dBm
• PoE Input: 1x 2.5 GbE RJ45 PoE+ (802.3at, 30W)
• Power Consumption: 22 W
• Max Clients Supported: 300
• Max SSIDs: 24
• Wireless Security: WPA-PSK, WPA-Enterprise, WPA2-PSK, WPA2-Enterprise, WPA3-PSK, WPA3-Enterprise
• IEEE Standards: 802.11a/b/g/n/ac/ax/be
• Operating Modes: Access Point
• Mounting Options: Wall or Ceiling
• Operating Temperature: -30 to 60°C (-22 to 140°F)
• Operating Humidity: 5% to 95% non-condensing
• Certifications: CE, FCC, IC
• Dimensions: 150 x 103 x 36 mm (5.9 x 4.1 x 1.4 in)
• Weight: 580 g (1.3 lb)
• Mobile App: UniFi (iOS & Android)
• UPC: 810084695579
• Package Contents:
  • UniFi U7 Pro Wall Access Point
  • Mounting Accessories
  • Quick Start Guide
