TP-Link TL-WPA7517 KIT AV1000 Gigabit Powerline AC Wi-Fi Kit (AC750)

The TP-Link TL-WPA7517 KIT AV1000 AC750 Powerline Wi-Fi Kit offers a seamless way to extend both your wired and wireless network throughout your home using your existing electrical wiring. Utilizing advanced HomePlug AV2 technology, this powerline extender delivers reliable data transfer speeds of up to 1000 Mbps, making it ideal for HD streaming, online gaming, and large file transfers.

Featuring dual-band Wi-Fi with 300 Mbps on the 2.4 GHz band and 433 Mbps on the 5 GHz band, the TL-WPA7517 ensures a stable, interference-free wireless experience across your home. With features like Wi-Fi Auto-Sync, Gigabit Ethernet ports, and OneMesh™ support, this kit offers a modern solution for consistent, high-performance connectivity.

Product Features

AV1000 High-Speed Powerline Performance

Delivers up to 1000 Mbps over your home’s electrical circuit for high-speed wired and wireless data transfer up to 300 meters—ideal for whole-home coverage.

Dual-Band AC750 Wi-Fi

Enjoy 300 Mbps on 2.4 GHz and 433 Mbps on 5 GHz for balanced, high-speed wireless connections across multiple devices with less interference.

Wi-Fi Auto-Sync

Automatically copies your router’s Wi-Fi name and password with the Wi-Fi Clone button. Any changes made to the router’s settings are automatically synced across your powerline network using Wi-Fi Move.

Gigabit Ethernet Ports

Each unit includes a Gigabit Ethernet port for stable wired connections to high-bandwidth devices such as smart TVs, gaming consoles, or desktop PCs.

Plug, Pair, and Play Setup

No configuration required. Simply plug in both adapters, press the Pair button, and enjoy secure, encrypted networking in minutes.

OneMesh™ Compatible

Easily expand and unify your home network with TP-Link OneMesh™ products for seamless Wi-Fi coverage without the need to replace existing hardware.

Remote Management via tpPLC App

Manage your powerline network using the tpPLC app on your smartphone or via the tpPLC Utility for PCs. View connected devices, change settings, and update firmware effortlessly.

Product Specifications

• Plug Type: US
• Networking Standards:
  • HomePlug AV2, HomePlug AV
  • IEEE 1901, IEEE 802.3, 802.3u, 802.3ab
  • IEEE 802.11b/g/n (2.4 GHz), 802.11a/n/ac (5 GHz)
• Powerline Transmission Speed: Up to 1000 Mbps
• Wireless Transmission Speed:
  • 2.4 GHz: 300 Mbps
  • 5 GHz: 433 Mbps
• Ethernet Interface:
  • TL-WPA7517: 1 × Gigabit Ethernet
  • TL-PA7017: 1 × Gigabit Ethernet
• Buttons: Pair, Reset, Wi-Fi Clone, LED On/Off
• Power Consumption:
  • TL-WPA7517: Max 11W, Typical 6.5W
  • TL-PA7017: Max 2.9W, Typical 2.6W
• Range: Up to 300 meters / 1000 feet over powerline
• Encryption:
  • Powerline: 128-bit AES
  • Wireless: WPA-PSK / WPA2-PSK / WEP
• Modulation Technology: OFDM (PLC)
• LED Indicators: Power, Powerline, Ethernet, Wi-Fi (2.4 GHz), Wi-Fi (5 GHz)
• Dimensions:
  • TL-WPA7517: 69.5 × 35 × 124.1 mm
  • TL-PA7017: 52 × 28.5 × 65 mm
• Operating Temperature: 0°C to 40°C (32°F to 104°F)
• Operating Humidity: 10% to 90% (non-condensing)
• Compatibility: Works with all HomePlug AV and AV2 standard adapters
• Certifications: CE, RoHS
• Package Contents:
  • 1 × TL-WPA7517 Powerline Wi-Fi Extender
  • 1 × TL-PA7017 Powerline Adapter
  • 2 × Ethernet Cables
  • Quick Installation Guide
• System Requirements: Windows 10/8.1/8/7/Vista/XP, Mac OS, Linux

The TP-Link TL-WPA7517 AC750 Powerline Kit is the ideal solution for users looking to extend reliable and high-speed internet to every room using the powerlines already in their walls—no rewiring required. Perfect for modern households, this kit offers stability, speed, and simplicity.
