TP-Link TL-SG1008MP 8-Port Gigabit Desktop/Rackmount Switch with PoE+

The TP-Link TL-SG1008MP is a high-performance 8-port Gigabit switch designed for both desktop and rackmount installations. All eight ports support the 802.3af/at PoE+ standard, allowing simultaneous power and data transmission over a single Ethernet cable. With a total PoE power budget of 126W and up to 30W per port, the TL-SG1008MP is ideal for powering wireless access points, IP cameras, and VoIP phones without additional wiring. Its plug-and-play design and built-in energy efficiency features make it a reliable and eco-conscious solution for expanding small to medium business networks.

Product Features

Full PoE+ Support on All Ports

Each of the 8 Gigabit RJ45 ports supports IEEE 802.3af/at PoE+, providing up to 30W per port for seamless integration of powered devices such as access points, IP cameras, and VoIP phones.

High Total Power Budget

With a combined power output of 126W, this switch can support multiple high-consumption PoE+ devices simultaneously, making it suitable for dense deployments.

Intelligent Overload Protection

The switch includes a priority function that prevents system overload by intelligently cutting power to the lowest-priority port when the overall PoE power consumption exceeds 126W.

Port Priority Management

Power priority is automatically assigned from Port 1 through Port 8. This ensures more critical devices retain power when the system is near or at its PoE power limit.

Eco-Friendly and Energy Efficient

Innovative energy-saving technologies reduce power consumption by up to 75% without sacrificing performance, aligning with modern green networking standards.

Plug-and-Play Simplicity

No configuration or software setup required. The switch supports automatic MDI/MDIX and auto-negotiation, allowing for effortless network expansion.

Desktop or Rackmount Flexibility

Designed for both desktop use and 19-inch rack installations, the TL-SG1008MP includes mounting brackets and rubber feet for flexible deployment options.

Product Specifications

• Model: TL-SG1008MP
• Ports: 8 x 10/100/1000 Mbps RJ45, PoE+ supported
• PoE Standard: IEEE 802.3af/at compliant
• Max PoE Budget: 126W total
• Max PoE per Port: 30W
• Switching Capacity: 16 Gbps
• Forwarding Rate: 11.904 Mpps
• MAC Address Table: 4K entries
• Buffer Size: 1.5 Mbits
• Jumbo Frame Support: 16 KB
• Power Supply: Internal, 100–240V AC, 50/60Hz
• Max Power Consumption:
  • 8.57W (no PoE load)
  • 173.65W (full 153W PoE load)
• Max Heat Dissipation:
  • 29.22 BTU/h (no PoE load)
  • 592.15 BTU/h (full load)
• Cooling: 1 built-in fan
• Dimensions: 294 × 180 × 44 mm (11.6 × 7.1 × 1.7 in)
• Mounting Options: Desktop or 1U rackmount
• Certifications: FCC, CE, RoHS
• Package Includes: Switch, power cord, installation guide, rackmount kit, rubber feet
• Operating Temperature: 0°C to 50°C (32°F to 122°F)
• Storage Temperature: -40°C to 70°C (-40°F to 158°F)
• Operating Humidity: 10% to 90% non-condensing
• Storage Humidity: 5% to 90% non-condensing
