TP-Link TL-SF1008P 8-Port 10/100Mbps Desktop Switch with 4-Port PoE+

The TP-Link TL-SF1008P is an 8-Port 10/100Mbps desktop switch designed for small business, home, or surveillance network setups. Featuring four Power over Ethernet (PoE+) ports compliant with IEEE 802.3af/at standards, it allows you to transmit both data and power via a single Ethernet cable. The TL-SF1008P offers a reliable, plug-and-play solution for powering IP cameras, VoIP phones, and wireless access points. Its extend and priority modes provide flexible deployment options and quality assurance for high-priority applications.

Product Features

4-Port PoE+ with 66W Power Budget

Equipped with 4 PoE+ ports supporting up to 30W per port, and a total PoE power budget of 66W—ideal for powering multiple PoE devices such as IP cameras or wireless access points.

Extended PoE Transmission Range

Enable Extend Mode to increase data and power transmission distance up to 250 meters, especially useful for surveillance setups requiring longer cabling.

Priority Mode for Critical Devices

Ports 1 and 2 support Priority Mode, ensuring critical applications like voice or video receive sufficient bandwidth and low latency.

Plug and Play Installation

No software or configuration required. Simply connect your devices and power on for immediate operation.

Silent Fanless Design

Fanless architecture ensures quiet operation, making it suitable for office or home environments where noise is a concern.

Product Specifications

• Ports: 8× 10/100 Mbps RJ45 ports, including 4× PoE+ ports
• PoE Standard: IEEE 802.3af/at compliant
• PoE Budget: 66W total, up to 30W per port
• Switching Capacity: 1.6 Gbps
• Forwarding Rate: 1.1904 Mpps
• MAC Address Table: 2K entries
• Jumbo Frame Support: 2 KB
• Transmission Method: Store-and-Forward
• External Power Supply: 53.5V DC / 1.31A adapter
• Power Consumption:
  • 2.3W max (no powered devices connected)
  • 73W max (with 66W of powered devices connected)
• Heat Dissipation:
  • 7.8 BTU/h (no PD connected)
  • 248.9 BTU/h (with 66W PD connected)
• Fan Design: Fanless
• Physical Security Lock: Yes
• Dimensions: 171 × 98 × 27 mm (6.7 × 3.9 × 1.1 in)
• Operating Temperature: 0–40°C (32–104°F)
• Storage Temperature: -40–70°C (-40–158°F)
• Operating Humidity: 10–90% RH non-condensing
• Storage Humidity: 5–90% RH non-condensing
• Certifications: FCC, CE, RoHS
• Advanced Software Features:
  • IEEE 802.3x Flow Control
  • Extend Mode (Ports 1–4)
  • Priority Mode (Ports 1–2)
  • MAC address auto-learning and auto-aging
  • Backpressure for half-duplex mode
• Package Contents:
  • TL-SF1008P Switch
  • Power Adapter
  • Installation Guide
