TP-Link TL-MR100 300 Mbps Wireless N 4G LTE Router

The TP-Link TL-MR100 is a powerful and easy-to-use wireless N router that enables high-speed 4G LTE connectivity for homes, remote offices, and mobile setups. Supporting download speeds of up to 150 Mbps, it lets you share fast internet with up to 32 wireless devices. With no configuration required, you can get online simply by inserting a nano SIM card. The MR100 also features WAN failover via its LAN/WAN port, and two high-gain external LTE antennas ensure stable connectivity even in signal-challenged areas.

Product Features

4G LTE Network Sharing

Share 4G LTE internet with up to 32 Wi-Fi-enabled devices simultaneously. Enjoy download speeds of up to 150 Mbps and a smooth online experience for streaming, browsing, and remote work.

Hassle-Free Setup with SIM Card

No need for technical setup. Simply insert a nano SIM card to instantly activate the internet connection. The MR100 is tested for compatibility with SIM cards from over 100 countries.

Enhanced LTE Coverage with Detachable Antennas

Two high-performance detachable antennas ensure stronger LTE signal reception and broader Wi-Fi coverage throughout your home or office.

WAN Failover for Uninterrupted Connectivity

When 4G is unavailable, the MR100 can switch to a wired broadband connection via its LAN/WAN port, offering flexible backup internet access.

Secure and Reliable Wireless

Equipped with WPA/WPA2 security protocols and firewall protections, the router helps secure your data and connected devices from potential threats.

Guest Network and Management Tools

Create a separate guest network to protect your main Wi-Fi. Admin tools such as system logs, firmware upgrades, and diagnostics make network management easy.

Product Specifications

• Brand: TP-Link
• Model: TL-MR100
• Wi-Fi Speed: Up to 300 Mbps at 2.4 GHz
• Wireless Standards: IEEE 802.11b/g/n
• Frequency: 2.4 GHz
• SIM Type: Nano SIM
• 4G LTE Bands:
  • FDD-LTE: B1/B3/B5/B7/B8/B20 (2100/1800/850/2600/900/800 MHz)
  • TDD-LTE: B38/B40/B41 (2600/2300/2555-2655 MHz)
• 3G Bands: HSPA/UMTS: B1/B5/B8 (2100/850/900 MHz)
• Ports:
  • 1 × 10/100 Mbps LAN Port
  • 1 × 10/100 Mbps LAN/WAN Port
  • 1 × Nano SIM Card Slot
• Buttons: WPS/Reset
• Antennas: 2 × Detachable External 4G LTE Antennas
• Transmit Power: < 20 dBm
• Reception Sensitivity:
  • 11g 54M: -74 dBm
  • 11n HT20: -71 dBm
  • 11n HT40: -68 dBm
• Wireless Functions: Enable/Disable Wireless Radio, Wireless Schedule, WMM, Wireless Statistics
• WAN Failover: Supported
• Security Features:
  • 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK
  • IPv4 SPI Firewall, IP and MAC Address Binding
• Operating Modes: 3G/4G Router Mode, Wireless Router Mode
• WAN Types: Dynamic IP, Static IP, PPPoE, PPTP (Dual Access), L2TP (Dual Access)
• Network Protocols: IPv4, IPv6
• Guest Network: 2.4 GHz
• DHCP: Server, DHCP Client List, Address Reservation
• Port Forwarding: ALG, Virtual Server, Port Triggering, UPnP, DMZ
• Dynamic DNS: DynDns, NO-IP
• Administration: System Logs, Firmware Upgrade, Factory Reset, Diagnostic Tools
• Dimensions: 154 × 114 × 36 mm
• Power Supply: 9V/0.85A
• Certifications: CE, RoHS
• System Requirements:
  • Windows 98SE/NT/2000/XP/Vista/7/8/8.1/10
  • macOS, NetWare, UNIX, Linux
  • Java-enabled browser: Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+
• Package Contents:
  • TL-MR100 Router
  • Power Adapter
  • RJ45 Ethernet Cable
  • Quick Installation Guide
• Operating Temperature: 0℃ to 40℃ (32℉ to 104℉)
• Storage Temperature: -40℃ to 70℃ (-40℉ to 158℉)
• Operating Humidity: 10% to 90% non-condensing
• Storage Humidity: 5% to 90% non-condensing
