D-Link 24-Port Cat6 Unshielded Fully Loaded Punch Down Patch Panel – Keystone Type – 1U – Black

The D-Link 24-Port Cat6 Unshielded Fully Loaded Punch Down Patch Panel is a robust and reliable networking component engineered for efficient cable organization and structured network distribution. This 1U keystone-type panel is ideal for data centers, enterprise networks, and telecommunications rooms, providing seamless performance for high-speed data transmission. With 24 RJ45 ports, this panel ensures a tidy and scalable solution for terminating and managing Cat6 cables while supporting Gigabit Ethernet and beyond.

Product Features

24-Port High-Density Design

This patch panel includes 24 preloaded RJ45 Cat6 keystone jacks, allowing for high-density cable management in a 1U rack space without sacrificing ease of access or performance.

Enhanced Signal Performance

Compliant with TIA/EIA-568C.2 Cat6 specifications, the panel ensures reliable high-speed data transmission up to 1 Gbps while minimizing crosstalk and signal degradation.

Durable Metal Construction

The panel and support bar are made of 1.5mm thick SPCC steel, painted black (RAL 9005) for a professional appearance and enhanced durability in high-usage environments.

Gold-Plated Contact Terminals

Each RJ45 jack features phosphor bronze contacts with nickel plating, finished with 50 micro-inches of gold plating on the plug contact area for optimal conductivity and corrosion resistance.

Universal Wiring Compatibility

The IDC terminals support both T568A and T568B wiring schemes, accommodating 22–26 AWG solid and stranded cable types. Compatible with standard 110 or Krone punch down tools.

Integrated ID Labels

Comes with transparent PVC identification plates and paper inserts to clearly label each port, simplifying maintenance and network documentation.

Flame-Retardant Housing and PCB

Components are made of UL-rated materials, including ABS and PC with flame ratings of UL 94V-0 and 94V-2, ensuring safe operation in professional networking environments.

Product Specifications

• Ports: 24 RJ45 (8P8C) Cat6 keystone ports
• Panel Material: SPCC steel, 1.5mm thickness, black (RAL 9005) painted
• Support Bar: SPCC steel, 1.5mm thickness, black (RAL 9005) painted
• Identification Plate: PVC, transparent, with writable paper inserts
• RJ45 Jack Housing: ABS, UL 94V-0 rated
• RJ45 Contact Bracket: PC, UL 94V-2 rated, transparent
• Contact Material: Phosphor bronze with nickel plating
• Contact Finish: 50 micro-inches gold plating
• IDC Housing: PC + Glass Fiber, UL 94V-2
• IDC Terminal: Phosphor bronze with tin plating
• Jack Bracket Set: ABS, UL 94V-0
• PCB: FR4, UL 94V-0
