180KG Single Door Electromagnetic Lock with LED and Signal Output – 12V/24V Maglock

The 180KG Single Door Electromagnetic Lock with LED and Signal Output is a robust, fail-safe maglock designed to provide high-security door access control across commercial, industrial, and institutional environments. Featuring strong holding force, status signal output, and an LED indicator for real-time lock status monitoring, this electromagnetic lock ensures secure door closure for wooden, glass, metal, and fire-rated doors. Engineered with anodized aluminum housing and a zinc-coated magnetic core and armature, it delivers reliable performance and durability for access control systems.

Product Features

High Holding Force for Enhanced Security

Delivers a powerful 180KG (350 lbs) holding force, ensuring the door remains firmly locked under power, ideal for secure areas requiring strong access control.

Fail-Safe Operation

The maglock releases when power is removed, making it compliant with emergency exit and fire safety requirements. Suitable for integration into emergency egress systems.

LED Status Indicator

Equipped with an LED light indicator for visual lock status feedback, helping users or security personnel verify door lock conditions at a glance.

Signal Output for System Integration

Includes signal output wiring for integration with access control systems, allowing monitoring and real-time system feedback through compatible control panels or devices.

Versatile Door Compatibility

Supports a wide range of door types including wooden, metal, glass, and fire-rated doors, making it adaptable to diverse installation environments.

Durable Construction

Built with anodized aluminum housing and zinc-plated magnetic components to ensure long-lasting performance, resistance to corrosion, and stable operation in varied conditions.

Product Specifications

• Lock Size: 200 × 41.7 × 21.7 mm
• Armature Plate Size: 130 × 33 × 10.5 mm
• Holding Force: 180KG (350 lbs)
• Voltage: DC12V or DC24V (24V available upon request)
• Current Draw: 280mA @12V / 150mA @24V
• Signal Output: Yes (see model EL-350TS)
• Compatible Doors: Wooden, Glass, Metal, Fireproof
• Surface Temperature: ≤20°C
• Operating Temperature: -10°C to 55°C (14°F to 131°F)
• Humidity Tolerance: 0–90% (non-condensing)
• Magnet Shell Finish: Anodized aluminum with surface texture processing
• Magnet & Armature Finish: Zinc-plated
• Weight: 1.2 kg
