12 Core Alarm Cable White – 100m Drum | Security Grade Cable for Alarm Systems

The 12 Core Alarm Cable (White, 100m Drum) is a premium-grade cable designed specifically for wired security alarm systems in both residential and commercial installations. Manufactured to BS 4737 standards, this multi-core cable features tinned annealed copper conductors with PVC insulation and a tough, tear-resistant sheath that includes a nylon rip cord for easy and safe stripping. Its construction ensures long-lasting performance and reliable signal transmission, even in demanding low-voltage, low-current applications such as alarm systems, access control, and automation.

Product Features

High-Quality Conductors

Each core is made from tinned annealed copper, offering excellent conductivity and corrosion resistance for long-term system reliability.

PVC Insulated and Sheathed

Both insulation and sheathing are made from durable PVC, making the cable robust and flexible while maintaining safety under varying environmental conditions.

Easy Installation

The cable includes a nylon rip cord under the sheath, making it simple to strip back without damaging the cores, saving time during setup.

Compliant with Security Standards

Manufactured to BS 4737 specifications, ensuring compatibility with industry-standard intruder alarm systems and other low-voltage signalling requirements.

Versatile Use

Ideal for intruder alarms, access control systems, intercoms, and other signalling applications requiring multi-core cabling over extended distances.

Product Specifications

• Cable Type: Security alarm cable
• Number of Cores: 12
• Core Colours: Red, Yellow, Black, Blue, White, Green, Orange, Brown, Grey, Pink, Violet, Turquoise
• Conductor Material: Tinned annealed copper
• Insulation Type: PVC
• Sheath Type: PVC with nylon rip cord
• Cable Length: 100 meters
• External Diameter: 6.1mm
• Maximum Conductor Resistance: 95 Ω/km
• Operating Temperature Range: -15°C to +70°C
• Minimum Bending Radius: 6x outer diameter
• Colour: White
• Packaging Type: Supplied on a drum
• Standards Compliance: BS 4737
• Weight: 0.035 kg per meter
• UNSPSC Code: 26121604
• Warranty: 1 Year
